6KV Surge Protection 360 Watt LED Explosion Proof Flood Light Zone 1&2

Ask Lasest Price
Brand Name :	KHJ
Model Number :	Ex-KT240,Ex-KT300,Ex-KT360
Certification :	ATEX,IECEx,CE,RoHS
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	400pcs per day
Delivery Time :	3-8 work days

Add to Cart

Product Details
Company Profile

6KV Surge Protection 360 Watt LED Explosion Proof Flood Light Zone 1&2

LED Explosion Proof Flood Light,Ex tank series,Zone 1&2,Zone 21&22, Surge Protection 6KV

LED Explosion Proof Flood Light,Ex tank series,160W,200w,240W, Zone 1&2,Zone 21&22

Highlight:LED Explosion Proof Flood Light Zone 1&2,Zone 21&22

Features And Benefits:

1. High efficacy LED Source with long lifespan>100,000 hoursz.

2. Robust aluminium housing and strong tempered glass.

3. Modular design allows great flexibility.

4. 6KV Surge Protection.

5. 5-year performance warranty.

Product Differentiation:

Type Of Protection	Ex db ,Ex tb
Protection Standards	(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-28, (IEC)EN 60079-31 EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8
Area Classfiction	Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1, Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2
Installation	(IEC)EN 60079-14
Certificate	pending
Equipment Coding	II 2 G Ex db IIC T* Gb II 2 D Ex tb IIIC T* Db IP66
Temperature Class	Rated power (W)	-40℃ ≤ Ta ≤ +55℃
		Gas	Dust
	240W~360W	T5	T95℃
ATEx Coding	II 2 G / II 2 D
Ingress Protection	IP66 (IEC)EN 60529
Cable entry	M201.5,M251.5,3/4 NPT
CE Mark	The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively. The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC Type Examination and compliance with the Essential Health and Safety Requirements

Applications:
It is ideally suited for oil & gas, chemical, petrochemical and other potentially explosive industrial environments
1. Oil&Gas Exploration
2. Drilling
3. Oil Refinery
4. Petrochemical Plant
4. Other potentially explosive industrial environments

Ordering information:

P/N	Operating Voltage(V)	Luminous Flux(lm)	Power(W)	CRI	Color Temp.	CCT(K)	Temp. Classiﬁcation
Ex-KTK240**CH-P3-E	100-277 VAC (141-392 VDC)	33520	240	70	Cool white	5700±300k	T5
Ex-KTK240**NH-P3-E		33520		70	Natural white	5000±300k	T5
Ex-KTK240**NH-P3-E		33520		70	Natural white	4000±300k	T5
Ex-KTK240**WM-P3-E		30168		70	Warm white	3000±300k	T5
Ex-KTK300**CH-P3-E		43500	300	70	Cool white	5700±300k	T5
Ex-KTK300**NH-P3-E		43500		70	Natural white	5000±300k	T5
Ex-KTK300**NH-P3-E		43500		70	Natural white	4000±300k	T5
Ex-KTK300**WM-P3-E		31950		70	Warm white	3000±300k	T5
Ex-KTK360** CH-P3-E		51120	360	70	Cool white	5700±300k	T5
Ex-KTK360** NH-P3-E		51120		70	Natural white	5000±300k	T5
Ex-KTK360** NH-P3-E		51120		70	Natural white	4000±300k	T5
Ex-KTK360** WM-P3-E		46008		70	Warm white	3000±300k	T5

Remarks:

1. The ﬁrst * stands for Operating Voltage including default -100-277VAC,D-347-480VAC.

2. The second * stands for Candela Distribution including H3V3,H5V5,H6V6.
