    UL844 UL1598A Class 1 Div 2 Led Flood Light Explosion Proof Light Fixtures 200W 240W

    Ask Lasest Price
    Brand Name : KHJ
    Model Number : Ex-KPLB200, Ex-KPLB240
    Certification : UL,CE,RoHS
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 400pcs per day
    Delivery Time : 3-8 work days
    • Product Details
    • Company Profile

    UL844 UL1598A Class 1 Div 2 Led Flood Light Explosion Proof Light Fixtures 200W 240W

    UL844 & UL1598A Explosion Proof LED Flood Light 200W 240W Polar Bear Series


    UL844 & UL1598A certified 200W 240W Explosion Proof LED Flood Light Polar Bear Series.


    Highlight: 200W 240W Explosion Proof LED Flood Lights, UL844 & UL1598A certified luminaire.


    Features And Benefits:

    1. High efficacy LED Source with long lifespan>50,000 hours.

    2. Copper-free aluminium alloy housing.

    3. UL844 & UL1598A certified.

    4. Lifespan>50,000 hours.

    5. 5KV surge protection.

    6. THD<10%.


    Product Important Information:

    Type Of ProtectionClass Ⅰ Division 2
    Protection Standards

    UL 844 - Luminaires for Use in Hazardous

    UL 1598 - Luminaires.

    UL 8750 - Light Emitting Diode (LED) Equipment for Use in Lighting Products

    UL 1598A - Supplemental Requirements for Luminaires for Installation on Marine Vessels

    CSA C22.2 No. 137-M1981 - Electric Luminaires for Use in Hazardous Locations

    CSA C22.2 No. 250.0-08 - Luminaires

    CSA C22.2 No. 250.13 - Light Emitting Diode (LED) Equipment for Lighting Applications.

    Area ClassfictionDivision Ⅱ
    InstallationNFPA70
    Certificate20170914-E491372
    Equipment Coding

    Class Ⅰ Division 2, Groups A,B,C,D

    UL 1598A
    UL 1598

    Temperature ClassRated power (W)-40℃ ≤ Ta ≤ +50℃-40℃ ≤ Ta ≤ +45℃-40℃ ≤ Ta ≤ +40℃
    200W-240W/T4T4A
    UL CodingClass Ⅰ
    Ingress ProtectionIP66 (IEC)EN 60529
    Cable entryM20*1.5 or M25*1.5 and 3/4 NPT
    UL Mark

    The UL marking of this product applies to NEC 500.

    The Equipment is declared to meet the provisions of the NEC 500 by reason of the UL.

    Type Examination and compliance with the Essential Health and Safety Requirements.

    Applications

    LED Explosion Proof Flood Light with UL844 & UL1598A certified, suitable for hazardous areas and marine vessels.



    Ordering information:

    P/NOperating Voltage(V)Luminous Flux(lm)Power(W)CRIColor TempCCT(K)Class I, Division 2 Groups A,B,C,D
    -40°C to 40°C-40°C to 45°C-40°C to 50°C
    Ex-KPLB200*WM-UL-E

    100-277 AC(141-392 DC)

    2730020070Warm white3000±300T4AT4/
    Ex-KPLB200*NH-UL-E2940020070Natural white4000±300T4AT4/
    Ex-KPLB200*NH-UL-E2940020070Natural white5000±300T4AT4/
    Ex-KPLB200*CH-UL-E2940020070Cool white5700±300T4AT4/
    Ex-KPLB240*WM-UL-E3276024070Warm white3000±300T4AT4/
    Ex-KPLB240*NH-UL-E3528024070Natural white4000±300T4AT4/
    Ex-KPLB240*NH-UL-E3528024070Natural white5000±300T4AT4/
    Ex-KPLB240*CH-UL-E3528024070Cool white5700±300T4AT4/

    Remarks:

    1. * Stands for beam angle,including H1V1 / H4V4 / H5V5 / H6V6 /FW;

    2. For Beam angle H1V1,H4V4 and H5V5,the luminous flux will be 15% less;

    3. For Beam angle FW the luminous flux will be 30% less.
