Weatherproof 30 To 60 Watt LED Explosion Proof Flood Light Goldenfrog Series

Ask Lasest Price
Brand Name :	KHJ
Model Number :	Ex-KGF30,Ex-KGF60
Certification :	ATEX,IECEx,CE,RoHS
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	400pcs per day
Delivery Time :	3-8 work days

Add to Cart

Product Details
Company Profile

Weatherproof 30 To 60 Watt LED Explosion Proof Flood Light Goldenfrog Series

Weather proof hazardous area lighting Ex Goldenfrog series LED Explosion Proof floodlight 30W 60W

Explosion proof LED Flood light: 30W 60W

Highlight: LED Explosion proof flood light

Features And Benefits:

1. IECEx/ATEX (Zone 1, 21, Zone 2, 22)

2. High strength aluminum alloy housing plus strong tempered glass cover.

3. High-efficiency LED lighting fixture, more energy saving than conventional light fittings.

4. Beam Distribution: Narrow, Medium, Wide.

5.Come with 2 cable entries for Loop-in and Loop out installation.

6.Low THD<10%, less interference.

7.Power factor>0.98.

8.5 years warranty.

Product Important Information:

Type Of Protection	Ex d, Ex t
Protection Standards	(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-31 EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8
Area Classfiction	Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1, Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2
Installation	(IEC)EN 60079-14
Certificate	LCIE 12 ATEX 3070 X			IECEx CQM 12.0033x
Equipment Coding	Ex d IIB T5 or T6 Gb Ex t IIIC T95℃ or T80℃ Db IP66			Ex d IIB T5/T6 Gb Ex t IIIC T95℃/T80℃ Db IP66
Temperature Class	Rated power (W)	-40℃ ≤ Ta ≤ +40℃			-40℃ ≤ Ta ≤ +55℃
		Gas	Dust		Gas	Dust
	30W	/	/		T6	T80℃
	60W	T6	T80℃		T5	T95℃
ATEx Coding	II 2 G / II 2 D
Ingress Protection	IP66 (IEC)EN 60529
Cable entry	M201.5 or M251.5 and 3/4 NPT
CE Mark	The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively. The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC Type Examination and compliance with the Essential Health and Safety Requirements

Applications:

The Ex-Goldentfrog series Explosion proof LED Floodlight fixtures are normally used in oil and gas production,chemical and petrochemical plants, off-shore platforms, refineries, Pharmaceutical and any other industry where hazardous atmospheres (gas and combustible dust) are potentially present.

Ordering information:

P/N	Operating Voltage(V)	Luminous Flux(lm)	Power (W)	CRI	Color Temp.	CCT(K)	Beam Distribution	Temp. Classification
Ex-KGFF30WM-E	100~240 AC (141~339 DC)	2992	30	80	Warm white	3000±300	180°	T6
Ex-KGFF30NH-E		3307	30	70	Natural white	4000±300	180°	T6
Ex-KGFF30NH-E		3307	30	70	Natural white	5000±300	180°	T6
Ex-KGFF30CH-E		3307	30	70	Cool white	5700±300	180°	T6
Ex-KGFB30WM-E		3780	30	70	Warm white	3000±300	80°	T6
Ex-KGFB30NH-E		4095	30	70	Natural white	4000±300	80°	T6
Ex-KGFB30NH-E		4095	30	70	Natural white	5000±300	80°	T6
Ex-KGFB30CH-E		4095	30	70	Cool white	5700±300	80°	T6
Ex-KGFS30WM-E		2992	30	80	Warm white	3000±300	15°	T6
Ex-KGFS30NH-E		3307	30	70	Natural white	4000±300	15°	T6
Ex-KGFS30NH-E		3307	30	70	Natural white	5000±300	15°	T6
Ex-KGFS30CH-E		3307	30	70	Cool white	5700±300	15°	T6
Ex-KGFF60WM-E		5670	60	80	Warm white	3000±300	180°	T6/T5
Ex-KGFF60NH-E		6300	60	70	Natural white	4000±300	180°	T6/T5
Ex-KGFF60NH-E		6300	60	70	Natural white	5000±300	180°	T6/T5
Ex-KGFF60CH-E		6300	60	70	Cool white	5700±300	180°	T6/T5
Ex-KGFB60WM-E		7245	60	70	Warm white	3000±300	80°	T6/T5
Ex-KGFB60NH-E		7560	60	70	Natural white	4000±300	80°	T6/T5
Ex-KGFB60NH-E		7560	60	70	Natural white	5000±300	80°	T6/T5
Ex-KGFB60CH-E		7560	60	70	Cool white	5700±300	80°	T6/T5
Ex-KGFS60WM-E		5670	60	80	Warm white	3000±300	15°	T6/T5
Ex-KGFS60NH-E		6300	60	70	Natural white	4000±300	15°	T6/T5
Ex-KGFS60NH-E		6300	60	70	Natural white	5000±300	15°	T6/T5
Ex-KGFS60CH-E		6300	60	70	Cool white	5700±300	15°	T6/T5

Remark:

1. Operating voltage including Default-100~240V AC; A-24-48V AC/DC; B-10-30V DC.
