Explosion Proof LED High Bay Lighting Ex Tank Series 320W400W480W Zone 1 IIC

Ex Tank Series 320W,400W and 480W Explosion Proof LED High Bay Lighting

Highlight: Explosion Proof LED High Bay Lighting, Ex lighting high power

Features And Benefits:
1. Explosion proof design suitable for Zones 1 and 2 (Ex-gas) and Zones 21 and 22 (Ex-dust) hazardous areas.
2. 50,000 hours rated life – eliminates need for frequent lamp replacement.
3. Tempered and impact-resistant glass globe, heat- and corrosion-proof.
4. Lead-free and environmentally friendly.
5. 320W,400W and 480W available. Optional luminous intensity distribution for different applications.

6. All external hardware are stainless steel.

Product Important Information:

Type Of Protection	Ex db ,Ex tb
Protection Standards	(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-28, (IEC)EN 60079-31 EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8
Area Classfiction	Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1, Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2
Installation	(IEC)EN 60079-14
Certificate	pending
Equipment Coding	II 2 G Ex db IIC T* Gb II 2 D Ex tb IIIC T* Db IP66
Temperature Class	Rated power (W)	-40℃ ≤ Ta ≤ +55℃
		Gas	Dust
	320W~480W	T5	T95℃
ATEx Coding	II 2 G / II 2 D
Ingress Protection	IP66 (IEC)EN 60529
Cable entry	M20*1.5,M25*1.5,3/4 NPT
CE Mark	The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively. The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC Type Examination and compliance with the Essential Health and Safety Requirements

Focus on security and energy-saving, Carry brightness and Sustainable future.
