LED Atex Lighting,200W,240W, energy saving, low maintenance
LED Atex Lighting,200W,240W, energy saving, low maintenance
Highlight: LED Atex Lighting,200W,240W,Zone 2
Features And Benefits:
1. High efficacy LED Source with long lifespan>50,000 hours.
2. Robust aluminium alloy housing and strong tempered glass.
3. Environmentally friendly, no mercury.
4. ATEX and IECEx Certified.
5. Five years full performance warranty.
Product Important Information:
| Type Of Protection | Ex nR,Ex tc |
| Protection Standards | (IEC)EN 60079-0, (IEC)EN 60079-15,(IEC)EN 60079-31 EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC
62321-7-2, IEC 62321-8 |
| Area Classfiction | Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1, Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2 |
| Installation | (IEC)EN 60079-14 |
| Certificate | IECEx CQM 13.0044X | LCIE 14 ATEX 1014 X |
| Equipment Coding | Ex nR IIC T4 or T5 or T6 Gc Ex tc IIIC T130℃ or T95℃ or T80℃ Dc IP66 | Ex nR IIC T* Gc Ex tc IIIC T* Dc IP66 |
| Temperature Class | Rated Power | Rated Voltage | -40℃ ≤ Ta ≤ +40℃ | -40℃ ≤ Ta ≤ +55℃ |
| Gas | Dust | Gas | Dust |
| 200W | 100~130VAC 220~240VAC 50/60Hz | T6 | T80℃ | T5 | T95℃ |
| 240W | T5 | T95℃ | T4 | T130℃ |
| ATEx Coding |  II 2 G / II 2 D |
| Ingress Protection | IP66 (IEC)EN 60529 |
| Cable entry | M20*1.5 or M25*1.5 and 3/4 NPT |
| CE Mark | The CE marking of this product applies to EU directives 2014/35/EU,
2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively. The Equipment is declared to meet the provisions of the ATEX
directive(2014/34/EU)by reason of the EC Type Examination and compliance with the Essential Health and
Safety Requirements |
Applications:
Can be widely used for hazardous area Zone 2 &22 where
flammable vapors, gases,ignitable dusts, fibers or flyings are
present; indoors or outdoors
1. Zone2&22 area
2. Gas station
3. Power plant
4. Warehouse
5. Other potentially explosive industrial environments
Ordering information:
| P/N | Operating Voltage(V) | Luminous Flux(lm) | Power(W) | CRI | Color Temp. | CCT(K) | Temp. Classification |
| Ex-KPLB200*WM-E |
100-277 AC (141-392 DC) | 27300 | 200 | 70 | Warm white | 3000±300 | T6/T5 |
| Ex-KPLB200*NH-E | 29400 | 200 | 70 | Natural white | 4000±300 | T6/T5 |
| Ex-KPLB200*NH-E | 29400 | 200 | 70 | Natural white | 5000±300 | T6/T5 |
| Ex-KPLB200*CH-E | 29400 | 200 | 70 | Cool white | 5700±300 | T6/T5 |
| Ex-KPLB240*WM-E | 32760 | 240 | 70 | Warm white | 3000±300 | T5/T4 |
| Ex-KPLB240*NH-E | 35280 | 240 | 70 | Natural white | 5000±300 | T5/T4 |
| Ex-KPLB240*NH-E | 35280 | 240 | 70 | Natural white | 4000±300 | T5/T4 |
| Ex-KPLB240*CH-E | 35280 | 240 | 70 | Cool white | 5700±300 | T5/T4 |
Remarks:
1. * Stands for beam angle,including H1V1 / H4V4 / H5V5 / H6V6 /FW
2. For Beam angle H1V1,H4V4 and H5V5,the luminous flux will be 15%
less
3. For Beam angle FW,the luminous flux will be 30% less
Why buy from us instead of buying from other suppliers?
1. Good location and convenient transportation.
2. ATEX, IECEx, CE, RoHS certification.
3. Advanced production and processing equipment, environmentally
friendly and reliable products.
What are our advantages?
1.Professional lighting manufacturer for more than 10 years.
2. Gold supplier.
3. Provide high quality products and best service.
