ATEX Approved Portable Explosion Proof LED Light fixture with
battery backup for hazardous area
10W 15W Explosion Proof Portable Light for hazardous area.
Highlight: ATEX Certified Portable Explosion proof led floodlight with
lithium rechargeable Battery.
Features And Benefits:
1. Hazardous Location Portable LED Work Lights, ATEX Certified.
2. Compact and lightweight high strength housing, shock and impact
resistance.
3. 15W and 10W options, Battery duration 6 hours on 15W and 10
hours on 10W.
4. High efficacy LED with long lifespan more than 50,000 hours.
5. Over-charge and Over-discharge Protection.
6. Stainless steel stand and carrying handle, easy to take.
7. Battery capacity checking function.
8. Ambient temperature from -20℃ to 55℃.
9. 3 Years performance warranty.
Product Important Information:
| Type Of Protection | Ex db, Ex tb |
| Protection Standards | (IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-28, (IEC)EN
60079-31
EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3,
EN 60598-1, EN 60598-2-5, EN 62031, EN 62493,
IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC
62321-7-2, IEC 62321-8 |
| Area Classfiction | Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1,Zone 21 and Zone 22
Areas to (IEC)EN 60079-10-2 |
| Installation | (IEC)EN 60079-14 |
| Certificate | EPT 18 ATEx 2977 X, IECEx CQM 15.0039X |
| Equipment Coding | Ex db op is IIC T* Gb,Ex tb op is IIIC T* Db |
| Temperature Class | Rated power (W) | -20℃ ≤ Ta ≤ +55℃ |
| Gas | Dust |
| 10W | T6 | T80℃ |
| 15W | T6 | T80℃ |
|
| ATEx Coding |  II 2 G / II 2 D |
| Ingress Protection | IP66 (IEC)EN 60529 |
| Cable entry | Not applicable |
| CE Mark | The CE marking of this product applies to EU directives 2014/35/EU,
2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively.
The Equipment is declared to meet the provisions of the ATEX
directive(2014/34/EU)by reason of the EC
Type Examination and compliance with the Essential Health and
Safety Requirements |
Applications:
Use in areas of Offshore, drilling rigs ,Petrochemical plants,
refineries, tank farm, aircrafts and paint spray booth or plant
turn-around, marine work areas, maintenance work area. etc.
Ordering information:
| P/N | Operating Voltage(V) | Luminous Flux(lm) | Power(W) | CRI | Color Temp | CCT(K) | Temp. Classification |
| -20℃~+55℃ |
| Ex-KFF10H6V6WM-B-E |
100~277 AC (141~392 DC) | 1260 | 10 | 80 | Warm white | 3000±300 |
T6 |
| Ex-KFF10H6V6NH-B-E | 1365 | 10 | 70 | Natural white | 4000±300 |
| Ex-KFF10H6V6NH-B-E | 1365 | 10 | 70 | Natural white | 5000±300 |
| Ex-KFF10H6V6CH-B-E | 1365 | 10 | 70 | Cool white | 5700±300 |
| Ex-KFF15H6V6WM-B-E | 1890 | 15 | 80 | Warm white | 3000±300 |
| Ex-KFF15H6V6NH-B-E | 2047 | 15 | 70 | Natural white | 4000±300 |
| Ex-KFF15H6V6NH-B-E | 2047 | 15 | 70 | Natural white | 5000±300 |
| Ex-KFF15H6V6CH-B-E | 2047 | 15 | 70 | Cool white | 5700±300 |
What are our advantages?
1.Professional lighting manufacturer for more than 10 years.
2. Gold supplier.
3. Provide high quality products and best service.
4. Good production capacity and fast delivery.
Competitive advantages of our factory:
1. Very competitive price and high quality control.
2. Timely delivery.
3. ATEX, IECEx, CE, RoHS certification.
