Explosion proof-Tank Series flame Proof LED Light 160W-240W for Zone 1 & Zone 21

Ex-Tank Series Explosion Proof LED Light 160W 200W 240W

Highlight: Explosion proof led light ,flameproof light for outdoor lighting

Features And Benefits:

1. Explosion-protected LED luminaire for hazardous areas and harsh environments.

2. Highly efficient, long-lifespan and innovative.

3. Strong aluminum housing and tempered glass, Impact level:IK08.

4. Meanwell Led driver.

5. High efficacy Led source, whole luminaire efficacy up to 135lm/w.

6. Optional luminous intensity distribution for different applications.

6. Ambient temperature from -40℃ to 55℃.

7. Surge protection:6KV.

8. 5 Years performance warranty.

Product Important Information:

Type Of Protection	Ex db ,Ex tb
Protection Standards	(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-28, (IEC)EN 60079-31 EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8
Area Classfiction	Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1, Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2
Installation	(IEC)EN 60079-14
Certificate
Equipment Coding	II 2 G Ex db IIC T* Gb II 2 D Ex tb IIIC T* Db IP66
Temperature Class	Rated power (W)	-40℃ ≤ Ta ≤ +55℃
		Gas	Dust
	160W~240W	T5	T95℃
ATEx Coding	II 2 G / II 2 D
Ingress Protection	IP66 (IEC)EN 60529
Cable entry	M20*1.5,M25*1.5,3/4 NPT
CE Mark	The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively. The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC Type Examination and compliance with the Essential Health and Safety Requirements
